Thermal monocular 3.4-13.6x35 Owlset MCX30 VEOT-MC04
Термален монокуляр 3.4-13.6x35 Owlset MCX30 Monocular - VEOT-MC04
MCC Series follow the design of traditional optical equipment. It is a small, lightweight , simple operation, and a wide range of application scenarios for infrared handheld thermal imaging monocular. MCC Thermal scope has clear imaging and comfortable observation, suitable for mediumdistance and short–istance observation, it is an ideal equipment for outdoor night vision.
Boot up in 2 seconds and ready to use
400×300 IR resolution
3.4x optical zoom, 1x, 2x and 4x digital zoom
Built-in laser indicator to locate the target easily
1280×960 High Resolution LCOS Display Screen
PIP mode to highlight target clearly, connect App via WIFI to share anytime
Support 7 hours long operation time
| Infrared Detector | |
| Detector type | Vox |
| Detector resolution | 400 × 300, 12 μm |
| Spectral range | 8 to 14 μm |
| NETD | ≤40mk |
| Frame rate | 50 Hz |
| Lens | |
| Focal length | 35 mm; F1.0 |
| Focus | Manual |
| Field of view | 7.5°×5.6° |
| Optical zoom | 3.4x |
| Digital zoom | 1x, 2x and 4x |
| Power | |
| Battery type | Single, replaceable 18650 battery |
| Battery life | ≥ 7 hours |
| Interface | |
| USB | Type C (USB 2.0 standard),
supporting analog video and power supply |
| Video interface | USB Type C |
| External expansion | External Display and Bluetooth remote control |
| Mechanical interface | UNC ¼”-20 (Tripod mounting), Mechanical expansion interface |
| Display | |
| Display type | 0.4″ FLCOS |
| Resolution | 1280 × 960 |
| Eyepiece | Monocular, exit pupil distance≥12 mm, diopter adjustment: -4 to＋2 |
| Eyepiece zoom | 13.8x |
| Video output | Analog video |
| Functions | |
| PIP Mode | Upper left, Upper middle, Upper right, Closed |
| Image enhancement | Supported only when there is no laser indicator |
| Scene modes | Enhanced, Highlight and Natural |
| Ultra power saving mode | Turn WIFI off or reduce the screen brightness level |
| WIFI | Transmission of real-time video via WIFI for remote control in the
2.4G frequency band and within 15 meter |
| Color palettes | Black Hot, White Hot, Red Hot, Iron Hot, Blue Hot |
| Hot spot | Available |
| Compensation modes | Automatic, shutter and scene compensation |
| Laser | Supported only when a laser indicator is available, up to 200 m |
| System | |
| Language settings | Chinese or English |
| Start up | 2 s |
| Storage temperature range | -30 °C to 60 °C |
| Humidity | 10 % to 95 % non-condensing |
| Shock | 30 G at 11 ms half sine pulse (as per IEC60068-2-27) |
| Vibration | 10 Hz – 150 Hz – 10 Hz 0.15 mm (as per IEC60068-2-6) |
| Encapsulation | IP66, Drop 1 m |
| Certification | IP66, FCC, CE, RoHS, EAC, WEEE, un38.3, IEC 60825-1 Class 2 |
| Physical | |
| Weight | ≤350 g |
| Size (L × W × H) | 150 × 40 × 70 mm |
| Battery charger | Standard Battery charger (for China, US, UK, Australia and Europeand in compliance with FCC, CE, EAC and RoHS). |
| Accessories | Battery charger, single 18650 battery,USB Type C cable, lens cap,wrist strap, carry bag, quick start guide |
| Optional | Extended bracket |
IP66 encapsulation, rugged and durable
| Марка | Owlset |
|---|---|
| Magnification | 3.4-13.6x |
